Below are the detailed specifications of Nokia Lumia 520 as supplied the Nokia
- Primary camera sensor size: 5 MP
- Display size: 4”
- Processor name: Snapdragon™ S4
- Maximum talk time (3G): 9.7h
- Maximum standby time (3G): 390h
- Maximum music playback time: 52h
- Photo sharing: Share over Bluetooth;Facebook;Picasa;Flickr;Send as email attachment;Share on TV with Play to DLNA app;SkyDrive;PhotoBeamer
- Design
- Dimensions
- Height: 119.9 mm
- Width: 64.0 mm
- Thickness2: 9.9 mm
- Weight: 124 g
- Display and User Interface
- Display size: 4 ”
- Display resolution: WVGA (800 x 480)
- Display features: Brightness control, Orientation sensor, Ambient light sensor, Lumia Color profile
- Display colors: TrueColor (24-bit/16M)
- Aspect ratio: 15:9
- Pixel density: 235.0 ppi
- Display technology: IPS LCD
- Display height: 86.0 mm
- Display width: 52.0 mm
- Touch screen technology: Super sensitive touch
- Sensors: Ambient light sensor, Accelerometer, Proximity sensor
- Keys and Input Methods
- User Input: Touch
- Operating keys: Volume keys, Camera key, Power/Lock key
- Form factor
- Form factor: Monoblock touch
- Dimensions
- Hardware
- Connectivity
- SIM card type: Micro SIM
- Dual SIM: No
- Charging connectors: Micro-USB
- AV connectors: 3.5 mm audio connector
- System connectors: Micro-USB-B
- USB: USB 2.0
- Bluetooth: Bluetooth 4.0 + LE
- Bluetooth profiles: Object Push profile (OPP) 1.1, Hands-free profile (HFP) 1.5, Serial Port profile (SPP), Advanced Audio Distribution Profile (A2DP) 1.2, Audio/Video Remote Control Profile (AVRCP) 1.4, Service Discovery Application Profile (SDAP), Phone Book Access Profile (PBAP) 1.1, General Audio/Video Distribution Profile (GAVDP) 1.2
- Wi-Fi: WLAN IEEE 802.11 b/g/n
- WLAN Security: WPA2 (AES/TKIP), WPA, WPA-Personal, WEP, WPA2-Personal, WPA-Enterprise, WPA2-Enterprise, PEAP-MSCHAPv2, EAP-SIM, EAP-AKA
- NFC: No NFC
- Data Network
- WCDMA network: 900 MHz, 2100 MHz
- WCDMA max data speed DL: HSDPA – 21.1 Mbps
- WCDMA max data speed UL: HSUPA – 5.76 Mbps
- GSM network: 850 MHz, 900 MHz, 1800 MHz, 1900 MHz
- GSM max data speed DL: EGPRS 236.8 kbps
- GSM max data speed UL: EGPRS 236.8 kbps
- Power Management3
- Battery: BL-5J 3.7V 1430mAh
- Battery capacity: 1430 mAh
- Battery voltage: 3.7 V
- Removable battery: Yes
- Maximum standby time: 16.0 days
- Maximum talk time (2G): 17.4 h
- Maximum talk time (3G): 9.7 h
- Maximum music playback time: 52 h
- Maximum video playback time: 5.9 h
- Maximum cellular network browsing time: 6.5 h
- Maximum Wi-Fi network browsing time: 7.3 h
- Wireless charging: No
- Processor
- Processor name: Snapdragon™ S4
- Processor type: Dual-core 1 GHz
- Memory
- User data storage: In device, Memory card, SkyDrive cloud storage
- RAM: 512 MB
- Mass memory: 8 GB
- Expandable memory card type: MicroSD
- Maximum memory card size: 64 GB
- Free cloud storage: 7 GB
- Connectivity
- Qualcomm Snapdragon™ S4 Processor
- Performance
- Do more. Wait less: Tap into faster performance. The Snapdragon™ processor CPU cores enable extra performance when you need it and puts you in charge of running the most demanding applications, including gaming, photography, as well as business and personal productivity.
- Power consumption
- Less charging. More doing: The Snapdragon™ processor’s unique asynchronous technology enables each core to power up and power down independently, resulting in maximizing core performance level without wasting battery power.
- Technology
- Beyond mobile. And beyond all expectations: Snapdragon™ S4 processor is a highly integrated, mobile-optimized system on a chip that delivers dynamic, immersive experiences and powerful, battery-friendly performance that can put new possibilities in your hands.
- Performance
- Software and applications
- Productivity features
- Features (Personal information Management): Calculator, Clock, Calendar, Phonebook, Alarm clock, Reminders, To-do list, Phonebook with integrated social networks, OneNote, Wallet, Family Room, Kid’s Corner
- Business apps: Adobe acrobat reader free download, Lync (Corporate IM) free download, SkyDrive storage for documents and notes, Company Hub for enterprise applications, Office apps: Excel, Word, Powerpoint, OneNote
- Document formats supported: Excel, PDF, Word, OneNote, Powerpoint
- Syncronization: Exchange ActiveSync, Windows companion app, Mac companion app, Nokia Photo Transfer for Mac
- Sync content: Calendar, Video, Pictures, Music, Contacts
- Other Applications
- Game features: DirectX 11, Touch UI, XBox-Live Hub
- Graphics format: JPEG, BMP, TIFF, PNG
- Software platform & User Interface
- Software release: Windows Phone 8
- Productivity features
- Communications
- Email and Messaging4
- Email clients: Yahoo! Mail, Outlook Mobile, Gmail, Office 365, Nokia Mail, Windows Live / Hotmail / Outlook.com, MS Exchange Active Sync
- Email protocols: SMTP, IMAP4, POP3
- Email features: Viewing and editing of email attachments, Always up to date, Multiple simultaneous email accounts, Text-to-speech message reader, Email attachments, Conversational view on email, Linking multiple inboxes to one, Inbox filtering, HTML viewer
- Instant messaging: Google Talk, Twitter, Windows Live Messenger, WhatsApp, Yahoo! Messenger, Skype IM, Facebook
- Messaging features: Integrated text messaging and chat, Instant messaging, Concatenated SMS for long messages, List of recently used numbers, Audio messaging, Text-to-speech message reader, Text messaging, Unified MMS/SMS editor, Automatic resizing of images for MMS, Distribution lists for messaging, Multimedia messaging, Conversational chat style SMS, Unified inbox for SMS and MMS
- Call management
- Features (Call Management): Voice Commands, Call waiting, Voice mail, Integrated hands-free speaker, Call forwarding, Call logs: dialled, received and missed, Call history, Voice dial, Conference call, Skype voice call
- Supported amount of phonebooks: One integrated Phonebook
- Contacts: Unlimited
- Ringtones: Downloadable ringtones, MP3 ringtones
- Noise cancellation: Two microphone uplink noise cancellation
- Speech codecs: AMR-WB, GSM FR, AMR-NB, GSM HR, EFR, GSM EFR
- Email and Messaging4
- Device security
- Security
- Enterprise security features: Remote security policy enforcement
- General Security features: Remote device locking via Internet, Track and Protect via internet, Firmware update, Remote wipe of user data via Internet, Device lock, Device passcode, PIN code, Firmware and OS integrity check, Secure device start-up, Online back-up and restore, Application sandboxing and integrity check
- Advance security features: Lost device tracking, Browser integrated anti-phishing
- Data encryption: User data encryption for device
- Security
- Sharing and Internet
- Navigation
- Photography
- Main camera
- Primary camera sensor size: 5 MP
- Camera Focus Type: Auto focus with two-stage capture key
- Camera digital zoom: 4 x
- ZEISS optics: No
- Sensor size: 1/4 inch
- Main camera f-number/aperture: f/2.4
- Camera focal length: 28.0 mm
- Camera minimum focus range: 10.0 cm
- Camera image formats: JPEG/Exif
- Camera Flash Type: No Flash
- Main camera features
- Main camera – other features: Touch focus, Landscape orientation, Auto and manual exposure, Auto and manual white balance, Active toolbar, Full screen viewfinder, Geotagging, Automatic photo upload to web services, Full resolution photo and video upload
- Digital camera add-ons: Nokia Smart Camera, Cinemagraph lens, Panorama lens, Bing vision
- Image capturing
- Capture modes: Video, Still
- Scene modes: Automatic, Night portrait, Sports, Night, Close-up, Backlight
- White balance modes: Cloudy, Incandescent, Fluorescent, Daylight, Automatic
- Light sensitivity: Automatic, ISO 100, ISO 200, ISO 400, ISO 800
- Photos viewed by: Camera Roll, Month, Timeline, Photo editor, Favorites, Album, Photos from Social networks
- Main camera
- Music and Audio
- Music
- DRM support: PlayReady
- Audio features: Album graphics display in Music player, Audio Streaming, Music Player, Cloud music offline playback, Media Player, Podcasts, Cloud music playback
- Music format
- Codecs: MP3, AMR-NB, WMA 10 Pro, GSM FR, WMA 9, AAC LC, eAAC+/HEAACv2
- Audio playback file formats: ASF, MP4, AAC, AMR, MP3, M4A, WMA, 3GP, 3G2
- Radio
- Radio features: Internet Radio, FM radio
- Voice and audio recording
- Recording: Voice recording in MMS, Voice recording in OneNote
- Audio recording file formats: AMR
- Audio recording codecs: AMR-NB, GSM FR
- Audio recording features: Mono
- Music
- Video
- Main video camera
- Camera video resolution: 720p (HD, 1280 x 720)
- Camera video frame rate: 30 fps
- Camera video zoom: 4 x
- Video playback frame rate: 30 fps
- Video playback codecs: VC-1, Windows video, H.264/AVC, H.263, MPEG-4
- Video playback file formats: MP4, WMV, AVI, 3GP, 3G2, M4V, MOV
- Video recording formats: MP4/H.264
- Video white balance modes: Cloudy, Fluorescent, Incandescent, Automatic, Daylight
- Main video camera features
- Video streaming: YouTube browsing and video streaming, Progressive video download, Streaming from video services and internet
- Video recording features: Video light, Video zoom, Continuous autofocus
- Main video camera
- Environment
- Environmental features
- Materials: Free of PVC, Contains recycled metals, Free of nickel on the product surface, Free of BFR, rFR as in Nokia Substance List
- Energy efficiency: Automatic screen brightness adjustment, Battery Saver feature, Energy efficient charger
- Eco content and services: Available at Store, HERE Drive: route optimization, HERE Maps: pedestrian navigation
- Product is recyclable (up to): 100% recoverable as materials and energy
- User guide: Small printed guide, full on nokia.com, In-device user guide
- Packaging: Made of renewable materials, Containing up to 60% recycled materials, Minimized package, Packaging is 100 % recyclable
- Environmental features
- Accessibility
- Accessibility features
- Hearing: Vibrating alerts, TTY support, BT neckloop compatible
- Vision: Voice recognition, Vibrating alerts, Zoom, Voice Commands
- Physical skills: Speakerphone, Voice recognition, Audio messages, Voice Commands
- Accessibility features
- What’s in the box
- Box
- Sales Package: Nokia Lumia 520, High Efficiency Charger AC-20, Nokia Battery BL-5J , Nokia Charging and Data Cable CA-189CD, Nokia Stereo Headset WH-108, Quick guide
- Box
